Shacman F2000 12 Wheeler Dump Truck

Shacman F2000 12 Wheeler Dump Truck Description:

The Shacman F2000 Dump Truck has a tough body appearance, and the Cummins engine configured can bring you unparalleled strong power. Its reliability, durability and fuel economy will be the reasons why you like it.

The FAST gearbox has a wide range of speed ratios, can adapt to various working conditions, has a strong climbing ability, and has a small design speed ratio step, which saves fuel.

Shacman F2000 Dump Truck mainly from the front axle, rear axle, suspension system, frame and other configurations, the combination of different product configurations, according to the bearing capacity, drive form, will be divided into lightweight, composite version, enhanced version, super version of four version types, can meet different working conditions, different cargo volume user needs.

Shacman F2000 10 Wheeler Dump Truck for Sale | Truck Shacman

Shacman F2000 10 Wheeler Dump Truck for Sale | Truck Shacman

Shacman 12 Wheeler Dump Truck Specification:

Brand: Shacman 12 Wheeler Dump Truck

Drive model: Left or right driven hand, 8X4

Shacman 12 Wheeler Dump Truck Engine:

Engine model: Weichai WD12.420

Power(Kw/Hp): 309/420

Speed(r/min):2200

Idle speed(r/min):600-800

Max torque(N.m):1750

Type: mechanically control, diesel engine, 4-stroke,6-cylinder in line, inter-cooling and turbo-charging, euro-2 or euro-3 emission standard

Stroke(mm):126/155

Displacement(L):11.596

Min.fuel consumption(g/Kw.h):≦198

Engine oil filling volume:39L

The thermostat opened at 82℃

Oil pump: P12

Shacman 12 Wheeler Dump Truck Brakes:

Running brake: Dual circuiting compressed air brake

Parking brake: Rear wheel power spring brake

Auxiliary brake: Engine exhaust brake

Shacman F2000 Dump Truck Performance:

Max. running speed(km/h):90

Max. climbing capacity(%):20

Min. ground clearance(mm):318

Fuel consumption(L/100km):40

Shacman F2000 Dump Truck Electrics:

Starter: 5.58kw,24V

Alternator: 1.54kw(28V,55A)

Battery: 135AH

Dimension (mm):

Wheel base:1800+3600+1350

Front-wheel track:2036

Rear wheel track:1850

Front overhang: 1525

Rear overhang: 2060

Approach angle: 22°

Departure angle: 33°

Overall length: 10335

Overall width:2490

Overall height: 3450

Body dimension:7400X2300X1300/1400/1500(bottom 8mm and side 4mm)

Fuel tank(L): 380L

Weight(Kg):

GVW:31000

Front axle loading capacity:6500X2

Rear axle loading weight: 13000X2

Clutch: ∮430 diaphragm clutch

Gearbox Model: Fast Fuller 9JS180 gearbox with 9 forward and 1 reverse

Propeller shaft: ∮180 contrite gear propeller shaft

Front axle: Styre technology 6.5 tons

Rear axle: Styre 13 tons with hub reduction ratio 1:4.8

Chassis Various Widths: ladder structure with parallel straight

Rear suspension: inverted leaf spring with stabilizer

Steering Model: 8098 integral circuiting ball power steering

Ratio:22.2-26.2:1

Tyre: 12.00-20/12.00R20/12.00R22.5,11ps

Cabin: Man F2000 flat head with two seats and one sleep with A/C

Instrument panel: Combined instrument panel

Other: A/C, enlargement radiator, ABS, CD, electricity heated rear view windows
