60T Animals Transport Livestock Trailer

Fence Semi Trailer Description：

Fence cargo trailer was popular by logistics companies as its multipurpose application.It uses to load a wide range of products and materials, like sand, bags, poultry, etc. Also some bulk cargo, very widely used in the transportation industry.

Fence flatbed trailer can be used to load the containers after adopt the container locks for it.

TITAN production the sidewall trailer fence semi trailer adopts high-quality material, important accessories and configuration all adopt domestic and aboard brands.

Main beam adopts Q345 high strength steel, stability and safety when operating in harsh road conditions. This makes the product long service time, save maintenance costs and improve operating efficiency.

livestock poultry transport truck trailer side wall fence semi trailer

livestock poultry transport truck trailer side wall fence semi trailer

Livestock Truck Trailer Specification:

Model: 3 Axles 60 Ton Animals Transport Livestock Trailer

Transport: Agricultural and sideline products and some bulk cargo

Loading capacity(ton): 60-80T

Overall dimension: 13000mm * 2600mm *3200mm

Platform: 3mm-thick checkered plate

Axles: 3 axles , 13t/16 ton, 16 tons breaking lining

Suspension: Heavy duty mechanical suspension

Spring Leaf: 90(W)mmx13(Thickness)mmx10 layers or 100mmx12mmx12 (specially intended for overseas markets)

King Pin: JOST brand 2.0 or 3.5 inch (bolted or welded)

Tire: 12 units

Twist Locks: 4,8,12 sets (lifting or screw type)

ABS: Optional

Langing gear: JOST/FUWA

Brake system: WABCO brand

Voltage: 24V

Socket(Receptacle): 7-pin Socket (for 7 wire harness)

LED：LED lights

Tool Box: 1  PCS

Painting: polyurethane paint

Shipping method: By bulk cargo carrier, RORO or 40HQ container

Fence Semi Trailer Advantages:

1. The frame of TITAN side wall semi trailer adopts a space frame structure welded by longitudinal beams and integral penetrating beams, which can balance the strength, stiffness and toughness of the frame, with strong bearing capacity, prolong the service life of the vehicle, without deformation, and maximize work efficiency. .

2. The series of side wall trailer frames are all beam-type structures, and the longitudinal beams are straight or gooseneck.

3. The height of the livestock truck trailer web varies from 400 to 500, the longitudinal beam is welded by automatic submerged arc welding technology, and the transverse beam penetrates the longitudinal beam and is welded as a whole.

4. TITAN will also provide the most professional after-sale service to our customer. We will cover tarp on thepoultry transport truck trailer to protect fence trailer, which is totally for free.

Through this video, you can learn about different types of fence semi-trailers, as well as the process, testing, packaging and customer feedback, etc.

Welcome to leave your inquiry! We will provide more details, price, catalog, drawing, videos for you!
