Shacman L3000 4x2 Dump Truck

Shacman L3000 4x2 Dump Truck Description:

The Shacman 4x2 dump truck is equipped with a translucent sunshade on the top of the driver, which can form a certain shielding effect on the sunlight and prevent it from affecting the driver's sight. There are also edge lights on both sides of the sunshade, which can help oncoming vehicles to better judge the width of the vehicle at night and avoid them in time.

The Shacman 4x2 dump truck still uses a round hole-shaped air intake grille in grille, and the guide grooves on both sides can guide the airflow to the door panels on both sides during the high-speed driving of the vehicle, keeping the door panels clean and tidy.

The combined headlights of the price of shacman truck are arranged on the one-piece bumper. The high and low beams, fog lights, turn signals and LED daytime running lights are integrated. There is also a pedal in the middle of the bumper. Handrail for easy daily scrubbing of the windshield of price of shacman truck.

Price of Shacman L3000 4x2 for Sale | Dump Truck Shacman

Price of Shacman L3000 4x2 for Sale | Dump Truck Shacman

Shacman L3000 Dump Truck Specification:

Brand: Dump Truck Shacman

Drive model: Left or right driven hand, 4X2

Clutch: ∮430 diaphragm clutch

Gearbox Model: Fast Fuller 9JS135 gearbox with 9 forward and 1 reverse

Propeller shaft: ∮180 contrite gear propeller shaft

Front axle: Man technology 7.5 tons

Rear axle: Styre13 tons with hub reduction ratio 1:4.8

Chassis: Various widths, front 940mm and rear 780mm

Rear suspension: inverted leaf spring with stabilizer

Instrument panel: Combined instrument panel

Tyre: 12.00-20/12.00R20/12.00R22.5,11ps

Cabin: Man F3000 flat head with two seats and one sleep with A/C, 2 rear windows, mechanical clerestory, hydraulic suspension cab, hydraulic chair, metal bumper, USB, electrically reversal cab

Other: enlargement radiator, ABS

Shacman L3000 Engine:

Engine model: Weichai WP10.336

Power(Kw/Hp): 247/336

Speed(r/min):2200

Idle speed(r/min):600-800

Max torque(N.m):1250

Type: electrically control, diesel engine, 4-stroke,6-cylinder in line, inter-cooling and turbo-charging, euro-3 emission standard

Stroke(mm):125/147

Displacement(L):9.726

Min.fuel consumption(g/Kw.h):≦198

Engine oil filling volume:39L

Thermostat Opened at 82℃

Oil pump: Bosch

Steering

Model: 8098 integral circuiting ball power steering

Ratio:22.2-26.2:1

Brakes

Running brake: Dual circuiting compressed air brake

Parking brake: Rear wheel power spring brake

Auxiliary brake: Engine exhaust brake

Electrics

Starter: 5.58kw,24V

Alternator: 1.54kw(28V,55A)

Battery: 135AH

Dimension (mm)

Wheel base:3200+1350

Front-wheel track:1525

Rear wheel track:2036

Front overhang: 1850

Rear overhang: 1450

Approach angle: 28°

Departure angle: 30°

Overall length: 7550

Overall width:2490

Overall height: 3450

Body dimension:4800X2300X1300/1400/1500(bottom 8mm and side 4mm)

Fuel tank(L): 300L

Weight(Kg)

GVW:25000

Front axle loading capacity:7500

Rear axle loading weight: 13000X2

Performance:

Max. running speed(km/h):90

Max. climbing capacity(%):20

Min. ground clearance(mm):318

Fuel consumption(L/100km):40
