60 Ton Drop Side Trailer

Name: 60 Ton Drop Side Trailer
Rating: 0.00 (0 reviews)

Drop side trailer has a 1000mm high side wall structure design. It can carry 60 tons of bulk cargo. And TITAN also can provides 2/3/4 axle drop sided trailer with loading capacity from 40-100 tons.

SKU:

GTIN:

MPN:

Brand:

3 Axle Cargo Trailer Description:

Cargo semi trailer for sale was popular by logistics companies as its multipurpose application.It use to load a wide range of products and materials, like sand, bags, poultry etc. Also the some bulk cargo, very widely used in the transportation industry.

The side wall flatbed trailer can be use to load the containers after adopt the contianer locks for it. 3 axle semi trailer with side wall is the most advantages model in TITAN.

60 Ton Drop Side Trailer with Side Wall for Sale - TITAN Vehicle

Drop Side Trailer Specification:

Tare Weight: About 7.6T

Dimension(mm): 13000x2500x3050mm

Trailer Sides: 1500mm

Loading capacity(ton): ≤60T

Axles: 3 axles, 13T/16T ,FUWA/ BPW/ TITAN Brand

Tire: 12 units, 12.00R22.5 or 315/80R22.5

Rim: 9.00-22.5 or 9.75-22.5

Suspension: Mechanical, Bogie, Airbag suspension(China brand or BPW brand)

Spring Leaf: 90(W)mmx13(Thickness)mmx10 layers or 100mmx12mmx12 (specially intended for overseas markets)

King Pin: JOST brand 2.0 or 3.5 inch (bolted or welded)

Landing Gear: JOST brand D200T or Chinese brand 28tons(double-speed)

Main Beam: Height: 500mm, Upper plate:14mm, Middle plate:8mm, Bottom plate:16mm, Material:Q345B steel

Side Beam: 16mm or 18mm steel channel (material: Q235 steel)

Bottom Platform: 3mm-thick checkered plate

Brake Chamber: WABCO RE 6 relay valve; T30/30+T30 spring brake chamber(TKL brand), 45L air tank

Twist Locks: 4,8,12 sets (lifting or screw type)

Valve: WABCO valve (specially intended for oversea market)

ABS: Optional

Light: LED light (specially intended for oversea market)

Voltage: 24V

Socket(Receptacle): 7-pin Socket (for 7 wire harness)

Tool Box: 1m x 0.5m x 0.5m (The tool box contains 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar. Its size can be tailored to suit your needs)

Painting: Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats

Cargo Trailer Advantage:

1. TITAN Vehicle adopts high strength steel material to manufacture the sidewall cargo trailer, it can make the dry cargo trailer have a higher loading capacity and a longer service life.

2. To make sure the service life of the 3 axle cargo trailer, all the spare parts we adopt are world famous brand.

3. Drop side trailer floor is checker plate, this will keep the other bulk cargo more stable, like the bags, or long stuff.

4. Hight quality side wall, make sure the stable and safety of the loads.

Through this video, you can learn about different types of sidewall semi-trailers, as well as the process, testing, packaging and customer feedback, etc.
